SureCall Force5 Industrial Signal Booster Five-Band 80db (SC-5000-80-RM)


$5,999.00

60-Day Returns Free Shipping $100+ 3-Year Warranty

Overview

The SureCall FORCE-5 is an FCC rated Industrial Signal Booster available to approved certified installers only.  Built with High Linearity, it combines PCS and Cellular dual-bands with LTE and AWS frequencies for Verizon, AT&T and T-Mobile as a total cellular amplification solution. This full-featured amplifier includes adjustable gain control and automatic shutdown for maximum flexibility. Extremely competitively priced, it requires 1/5th the space requirements of its competitors and is a fraction of the cost compared to similar amplifiers with its capabilities. Ideal for locations with a low cellular signal and/or requiring large coverage. Covers up to 80,000 square feet (4,700m2) with good signal. Networks Covered The Force-5 boosts 800 MHz, 1900 MHz, AWS (T-Mobile and Canadian Carriers), AT&T, and Verizon 4G LTE networks. These frequencies cover the majority of all cell carriers in North America including:

  • AT&T 2G, 3G, 4G HSPA+ and 4G LTE
  • Verizon 2G, 3G and 4G LTE
  • Sprint 2G, 3G
  • T-Mobile 2G, 3G, 4G HSPA+ and 4G LTE
  • US Cellular 2G, 3G, and 4G LTE

Other carriers including Alltel, Boost Mobile, Virgin Mobile, and others! In the Box This product contains only the signal boosting amplifier and items listed below.  The Force-5 amplifier requires at least one outside antenna, one inside antenna, and cables to connect the antennas to the amplifier in order to operate. FORCE-5 amplifier AC power supply User manual Mounting kit   SureCall FORCE-5 Overview Video

Specifications

  • SKU
    SC-5000-80-RM
  • UPC
    858507006397
  • Impedance
    50 ohm
  • Gain (Up/Down)
    80dB / 80dB
  • Max Coverage
    Up to 80,000 sq ft
  • Frequencies Supported
    700MHz, 800MHz, 1900MHz, 1700/2100MHz
  • Power Requirements
    AC110V, 60Hz;
  • Max Output Power
    27 dBm with High Linearity
  • Noise Figure
    7dB
  • Specific Frequencies Supported
    698 - 716 MHz / 728 - 746 MHz, 776 - 787 MHz / 746 - 757 MHz, 824 - 849 MHz / 869 - 894 MHz, 1850 - 1910 MHz / 1930 - 1990 MHz, 1710 - 1755 MHz / 2110 - 2155 MHz

Regulatory Advisories

This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.

Please note, the four largest carriers - AT&T, T-Mobile, Verizon and Sprint - and more than 90 regional carriers have given blanket consent for use of all boosters certified to the new FCC standards.
