SureCall SC-DPLX-01 Wide-Band Diplexer

SureCall  |  SKU: SC-DPLX-01
$69.99

Do You Have a Question?
Our friendly signal experts are ready to help you.
Call us: 1-800-590-3564 or send us a message.

Description

The SureCall SC-DPLX-01 Wide-Band Diplexer, also known as a Frequency-Specific Combiner, is designed to split and combine two frequency ranges efficiently. It is commonly used when you have two amplifiers with a single inside and outside antenna, such as when one amplifier is a 700 MHz LTE-specific amp. It can also be used with two frequency-specific inside or outside antennas. This diplexer operates like a bi-directional splitter, sending one frequency range out of one port and the other frequency range out of the other port. The Low port handles 698 to 787 MHz, while the High port manages 824 to 2200 MHz. Each port features a 1.5dB insertion loss.

  • Wide Frequency Range: Splits cellular frequencies, accommodating LTE 700 MHz, Cellular 800 MHz, PCS 1900 MHz, and AWS 2100 MHz.
  • Low Insertion Loss: Maintains a low insertion loss of 1.5dB on both the Low and High ports.
  • High Isolation: Provides a high level of isolation between ports to prevent interference.
  • Compact Design: Features a small footprint, making it easy to integrate into various setups.
  • Bi-Directional Functionality: Can be used as a combiner in the reverse direction, allowing for versatile applications.
  • Robust Construction: Operates within a wide temperature range of -40°C to +85°C, ensuring durability and reliability.
  • 50 Ohm Impedance: Compatible with standard 50 Ohm signal booster systems.
  • Simple Installation: Requires two diplexers and four short jumper cables with N-Male connectors to use two amplifiers with a single inside and outside antenna.

The SureCall SC-DPLX-01 Wide-Band Diplexer is an excellent solution for managing multiple frequency ranges in your signal booster system, offering high performance, easy installation, and reliable operation across a wide range of frequencies.
